LM Router101-B
BACnet Router
LM BACnet router 101-B, a commonly device for building automation systems, based on the BACnet protocol. It provides 1 RS-485 serial port and 1 10/100 Mbps Ethernet ports.It can implement communication routing functions between the BACnet IP network and the BACnet MS/TP bus. The configuration is done through a web page, which is very convenient for users to operate.
Buy online
CPU | ARM926EJ,300MHz |
RAM | 64MByte High performance memory |
Nand Flash | 128MByte SLC Flash |
Serial port | RS485X1 |
Network port | 1 100M/10M Ethernet interface |
Wifi | Optional USB wireless network card |
Power | DC9V~48V |
Total Weight | 280g |
Enclosure rating | IP51 |
Mechanical Dimensions | 98.5mm×96mm×27mm(L×W×H) |
Mechanical installation | DIN rail card slot fixing |
Power consumption | The maximum power consumption of the motherboard is ≤2W |
Operating temperature | -40~85℃ |
Working relative humidity | 20 to 90% non-condensing |
-
Achieve transparent transmission between BACnet MS / TP and BACnet IP
-
Suitable for Johnson Controls, Siemens, Honeywell, Delta, Schneider and domestic series DDC,
Siemens VAV controller and other MSTP bus integration
-
Program upload and download of BA system software to DDC equipment
-
Support 2 MSTP buses at the same time, optically isolated MS / TP port; baud rate is 9.6-115.2kbps;
-
The configuration is completed through the web page, and the user operation is very convenient
-
10/100 Mbps Ethernet with adaptive and Auto-MDIX (Auto Line Sequence Crossover)
